Haier smart TV upgrade method Daquan, brush tutorial! [root tutorial]

Haier smart TV upgrade method Daquan, brush tutorial! Root tutorial



One, 181 movement: Software name: MERGE.bin. The software size is 2.53M. Enter this software into the USB flash drive, press menu 8893 to enter the factory, select the 6M181 Update (USB) item, and press the right button to perform the USB upgrade. If it is a gray screen state, press USB first; press menu 8893 to enter the factory to upgrade, and then select the EEP INIT for initialization. At the same time, adjust the POWER item to OFF. Note: must be U disk, the format must be FAT32. The upgrade process can not power off and pull U disk, otherwise it will crash.

Second, 6I988/6i981 movement: Software named USB.BIN. The software of this file name is entered into the USB flash drive and plugged into the USB interface. 1) Press menu 8893 to enter the factory and select the 6I988 Update system to start the upgrade. After the upgrade is complete, the machine will reboot. 2) Before AC power on, press and hold the “Menu” button of this control. The AC starts to upgrade after the power is turned on, and the indicator blinks to release the button. Note: This method is only used for the main program upgrade. After the upgrade is completed, the factory is selected to Factory Reset to perform factory initialization, and then the EEP Int item is selected for initialization.

Third, K58M3000P machine: Select the setting in the HOME interface, in the image state; press menu 8893 to enter the factory. You can view the 6M31 and X86 programs. The X86 software name is date, year, month, and day. The MCU consists of two digits, such as 17.57. The first two digits are the MCU software version number; the last two digits are the 6M31 version number. Select to enter the state of 6I48 to see the version number. Press the TV button at this time to switch to full screen. X86 upgrade method: First make a boot disk, in the WIN7 system will U disk format NTFS. Then right-management disk management - select your U disk, the partition marked as active partition.



Fourth, 6I78 movement: Software named TARGET. The software size is 37-39M. Enter this software into U disk and press menu 8893
Into the factory, first look at the version number before the upgrade is not registered to facilitate later observation whether to upgrade into. 1) Then select 6I78UPDATE (USB) and press the right key to start the upgrade. 2) Compress the software into the U disk, extract to the current folder, turn on the TV and then unplug the power, plug the U disk into the TV USB port, and then directly power on, the light starts flashing, indicating that the machine starts to upgrade , upgrade completed their own boot, unplug the power. Remove the U disk, and then boot, enter the factory to select EEPINIT to initialize, complete the POWER function is turned to the OFF state (to solve the power on the phenomenon of boot). Note: must be U disk, the format must be FAT32. The upgrade process can not power off and pull U disk, otherwise it will crash.

V. 6M20 software: The file name is MFC.BIN. The file is 44.3KB copied into the root directory of the U disk, inserted into the entire machine
USB1 port. Enter the factory menu to select 6M20 UPDATE, then press the right button to upgrade the machine automatically.

Six, 6M69 movement: Software name AP.BIN. The software size is 5.1M. 1) Insert the software into the root directory of the U disk, insert it into the USB interface, press menu 8893 into the factory, select 6M69DOWNLOAD, and press the right key to upgrade. The upgrade is automatically started. 2) Blind-up method: The software is entered into the root directory of the USB flash drive and plugged into the USB interface. Press the menu 8893 into the factory, press the arrow key, and then press the right key, the system will automatically upgrade. After the upgrade is complete, the system will boot automatically. Then enter the factory to select OtherSetting and press the right key to select INNT EEPROM for initialization. After the initialization is complete, you need to set the Power On Mod and AGING options to OFF. Otherwise, power on the device. Then select Panel Select. Note: must be U disk, the format must be FAT32. The upgrade process can not power off and pull U disk, otherwise it will crash.



7. The 5301C movement: The software is called upgrade_loader.pkg. The software is 76.9M. This software was tested in a USB flash drive and plugged into the USB interface. The AC power on, the indicator light flashes, and the machine is automatically upgraded. Need to be initialized after completion. Note: must be U disk, the format must be FAT32. The upgrade process can not power off and pull U disk, otherwise it will crash.

Eight, online TV upgrade method: boot screen upgrade (refer to LE42H320, LE46H320, LE55H320). Plug the U disk into the TV. The U disk requires the FAT32 format. The space remains at least 200 M. It is recommended that the U disk be formatted before upgrading. Make sure the network connection is normal, press the "TV menu" button on the remote control to enter the main menu, press the up/down button to select the function item, press the left/right button to select the network upgrade option, press the confirmation button twice to call out "Confirm whether network upgrade?" Prompt menu, select the confirmation item and press OK to perform network upgrade. After confirming that the network is upgraded, the TV enters the state of downloading the latest firmware and a “Downloading” progress bar appears. After the TV is downloaded and automatically decompressed, it will be automatically upgraded. During the upgrade, the TV will be blank and the indicator will blink, and the TV will restart manually after stopping flashing. update completed.

Nine, 6M48 movement: software file name: MERGE.BIN. The software is 3.65M. This software is tested on a USB flash drive and plugged into a USB interface. Press menu 8893 to enter the factory and select the last item "6M48 Update (USB)". Press the right key to start the upgrade. Then press EEP-INIT to proceed. initialization.

X. 8222 Movement: The name of the program upgrade file is: MTK22CPT.BIN. The software is 4.93M. This software is tested in a USB flash drive, plugged into a USB interface, and the source of the TV signal is cut to USB. Select a USB option for recording/music/picture/movie. Press OK. At this point, the screen will automatically prompt you -- --Whether to upgrade, and then press the OK button to start the upgrade, the screen prompts the file to be copied, and then prompts the upgrade. During the upgrade process, it cannot be powered off. The upgrade time is about 2 minutes. After the upgrade is complete, the TV will restart, press menu + 8893, enter the factory menu, select EEP INT, press the right key to enter the sub-menu, and then press the right key to start initialization EEPROM, clear all the data. Select "Factory Reset" and press OK to perform automatic initialization.

Eleven, RTD2674 movement: Software name changed to flash.img file. The software is 3.08M. Enter this software into USB flash drive, insert it into USB interface, press menu 8893 to enter factory, select RTD2674 DOWNLOAD item and press “volume+” to start upgrading; “Downloading” appears on the screen to indicate that it is upgrading; then it is initialized.

Twelfth, 742 movements: The movement of the machine core needs tooling upgrades. One end of the USB cable is male and one end is female. It is used to connect computers and upgrade small boards. Adaptation line one (printer line); a computer; ISP programming software tools. The USB cable is connected to the computer; the USB board is connected to the USB cable port. Place the tool software in any directory on the D drive. Put the program under the D drive. Only BIN files can be programmed. Double-click ISP-TOOL.EXE.

XIII, 2672 Movement: Click File-> Comm Settings. Select the corresponding port in the COM Port Selection ("My Computer" right -> "Properties" -> "Hardware" -> "Device Manager" -> "Port" can be used to see which USB to serial port to use) Click the button. Click the button marked in the above picture, select the last line "Dragon ROM code with CTRL+W" (via VGA upgrade), click the button, select the file (.spi file) used for the upgrade, and open it. Click the button, the following dialog box appears, indicating that in the communication connection, before the progress bar in the above figure is completed, the TV AC is powered on, the communication connection can be established, and the program can be erased immediately. The dialog box is as follows, and the progress bar ends. When the following dialog box is displayed, the programming is completed. Click the button or close the dialog box directly. Power off the TV AC, wait for the TV to completely power off (light off) and then power on. Enter the factory's main menu according to the method in the second section below. Select the "Factory Initialization" item and execute it to reinitialize the Eeprom. At this point, the upgrade process is complete.

Fourteen, M card M25 upgrade method: First in the state of the card press - Settings - System Settings - OK - and then press the status display to see the version number. The software is named C2-Update.tar. This software is checked into the root directory of the USB flash drive. No decompression is required. Then in the mode card state to enter the local ----- file --- find the file name of the software, select the press the confirmation button, this time will be prompted to upgrade please wait. Or you are upgrading software. Please do not turn off the power. After the upgrade is complete, reboot. Two software upgrade methods: 2011.03.10 program contains a total of 2 upgrade files, you need to upgrade 2 times (the first time you repeat the first step to upgrade), pay attention to distinguish between two kinds of software, the first upgrade software has a File (10.8.26 program, file size 42M, must be placed in the root directory), the second upgrade software has two files (2011.03.10 program, a 41.2M, another 7.19M, must be placed in the root directory) , respectively inserts and carries on the promotion; The promotion step is as follows: The first upgrade method is the same as above; After the promotion is complete, will prompt "restart" or will flash the blue screen, after this manual shutdown, pulls out the U disk, then TV Open, you will find the screen is a red or blue screen. At this time, turn off the TV, then insert the tested second USB flash drive into the USB1 of the SIM card, and then power it on. After the TV is opened, the interface of the card will appear. This is to wait about 2 minutes to start the automatic upgrade. After the upgrade is complete, you will be prompted to reboot. Unplug the USB flash drive after the DC power off. After powering on the USB flash drive, you cannot power off the card. Otherwise, the card will not boot.

Fifteen, M card M22 upgrade method: the software is named haier_tv_256_20100729-191856. This software is admitted to the root directory of the U disk. Insert the USB flash drive into the USB interface of the modular card; enter the local settings and select the system upgrade. The system upgrade will be displayed. Do not power off the USB flash drive. Then there is a progress bar showing that the card is automatically turned on after the upgrade is completed. update completed.

XVI. PW118 movement upgrade: Upgrade preparation: 1 serial cable (3, 4 pin cross), upgrade software mini_SDK file. The mini_SDK file includes the bin file and the embedded file 1 as shown below. There is a FlashUpgrader.exe upgrade tool in the bin file; the embedded file contains a bin file, which contains the program's hex file and installation information.
Execute bin\FlashUpgrader.exe. Connection and Baud are respectively set to Serial, 115200; "Modes" is selected to "Flash"; COM Port settings are the same as the default serial port of the computer.
1, through the path: My Computer / Properties / Hardware / Device Manager / Port (COM and LPT) to see the computer's default serial port. Other settings can be the default value
2. Click the "Choose..." button in the upper right corner of the upgrade screen. The following screen appears:
4. Standby or hard-shut the TV. Connect the RS-232 port of the computer and TV with the serial cable. In the open upgrade interface (above), use the mouse to click the Flash button at the bottom right of the upgrade interface; the progress bar on the lower right corner appears. Waiting for target reset...", then boot, the program will start to download to the flash chip, and the progress bar will show the current progress. After the upgrade is complete, the progress bar is restored to the pre-upgrade state. After the upgrade is complete, turn on the phone, dial 9,4,4,3 after the main menu is called out. At this time, the menu will enter the factory menu mode. The completion date and time of the program will be displayed in the upper part of the menu. Select the fourth sub-menu "Function", enter the third column Fac option, a green menu will appear in the upper left corner of the screen, select the second last item "Fac Reset" and press the "volume +" button. The machine will reset once.
